Battery Energy Storage Systems
Advanced LFP battery storage solutions for commercial, industrial and utility-scale energy projects
Advanced LFP battery energy storage solutions for commercial, industrial and utility-scale energy projects
Our portfolio supports peak shaving, renewable energy integration, backup power, grid stability, curtailment reduction and solar-plus-storage deployment.
The product portfolio includes outdoor C&I cabinets, all-in-one ESS systems, PV-storage charging systems, DC cabinets and utility-scale containerized BESS platforms. Systems are designed for high energy density, liquid cooling, outdoor deployment, IP-rated protection, communication integration and long-term project performance.
Commercial & Industrial BESS
Commercial and industrial BESS systems are designed for factories, campuses, commercial buildings, data centers, warehouses and high-load energy users. These systems support demand management, backup power, solar self-consumption, tariff optimization and operational resilience.
C&I Outdoor BESS Cabinet — 760 kWh
Technical Specifications
Energy Capacity760 kWh
Battery Cell300Ah
Configuration2P396S
CoolingLiquid-cooled
IP RatingIP55
CommunicationCAN, RS485, Ethernet
Dimensions2400 × 1400 × 2500 mm
Weight≈ 8000 kg
Max Altitude≤ 2000 m (derating above)
CertificationsUL9540A, UL9540, UL1973, UN38.3, UN3480, NFPA68, IEC62477-1, IEC 61000-6-2/4, IEC 63056, IEC 62619, IEC 60730-1, GB/T 36276
Features
- Industrial-grade outdoor deployment
- Liquid cooling for extended lifespan
- Multi-layer protection and safety systems
- Modular architecture for scalable deployment
C&I Outdoor BESS Cabinet — 836 kWh
Technical Specifications
Energy Capacity836 kWh
Battery Cell314Ah
Configuration1P416S
CoolingLiquid-cooled
IP RatingIP55
CommunicationCAN, RS485, Ethernet
Dimensions2400 × 1400 × 2420 mm
Weight≈ 8000 kg
Max Altitude≤ 3000 m (derating above)
CertificationsUL9540, UL1973, UL9540A, NFPA68, IEC62477, IEC61000, IEC63056, IEC62619, IEC60730, UN3480
C&I Outdoor BESS Cabinet — 522 kWh
Technical Specifications
Energy Capacity522 kWh
Battery Cell314Ah
Configuration1P260S
CoolingLiquid-cooled
IP RatingIP55
CommunicationCAN, RS485, Ethernet
Dimensions1900 × 1400 × 2420 mm
Weight≈ 8000 kg
Max Altitude≤ 4000 m (derating above)
CertificationsUL9540, UL1973, UL1741, UL9540A, NFPA68, NFPA69, UN3480
C&I Outdoor BESS Cabinet — 261 kWh
Technical Specifications
Energy Capacity261 kWh
Battery Cell314Ah
Configuration1P260S
CoolingLiquid-cooled
IP RatingIP55
CommunicationCAN, RS485, Ethernet
Dimensions1120 × 1350 × 2420 mm
Weight≈ 3500 kg
Max Altitude≤ 4000 m (derating above)
CertificationsUL9540, UL1973, UL1741, UL9540A, NFPA68, NFPA69, UN3480
All-in-One ESS — 125 kW / 261 kWh
Technical Specifications
System TypeAll-in-One ESS
Battery Cell314Ah
PCS Capacity125 kW
DC Capacity261 kWh
CoolingNatural (PCS) + Liquid (Battery)
IP RatingIP55
CommunicationRS485 / Ethernet
Dimensions800 × 1152 × 2373 mm
Weight≈ 2600 kg
Max Altitude≤ 3000 m (derating above 2000m)
CertificationsIEC62619, IEC62477, IEC61000, UN38.3
Features
- Integrated battery and power conversion
- Ready for immediate deployment
- Reduced installation and site preparation
DC Battery Cabinet — 261 kWh
Technical Specifications
System TypeDC Cabinet
Energy Capacity261 kWh
Battery Cell314Ah
CoolingLiquid-cooled
IP RatingIP55
CommunicationRS485 / Ethernet × 2
Dimensions1120 × 1350 × 2420 mm
Weight≈ 2550 kg
Max Altitude≤ 4000 m (derating above)
CertificationsIEC62619, IEC62477, IEC61000, UN38.3
Features
- Battery-only configuration
- Pairs with external PCS for flexibility
- Ideal for retrofit or custom integration
PV-Storage Charging ESS — 100 kW / 261 kWh
Technical Specifications
System TypePV-Storage Charging ESS
Battery Cell314Ah
PCS Capacity100 kW
DC Capacity261 kWh
CoolingLiquid-cooled
IP RatingIP55
CommunicationRS485 / Ethernet × 2
Dimensions1500 × 1350 × 2420 mm
Weight≈ 2650 kg
Max Altitude≤ 4000 m (derating above 2000m)
CertificationsIEC62619, IEC62477, IEC61000, IEC63056, UN38.3, UN3480
Features
- Optimized for solar + storage projects
- Direct PV charging capability
- Seamless solar integration
All-in-One ESS — 100 kW / 211 kWh
Technical Specifications
System TypeAll-in-One ESS
Battery Cell300Ah
PCS Capacity100 kW
DC Capacity211 kWh
CoolingLiquid-cooled
IP RatingIP55
CommunicationRS485 / Ethernet
Dimensions1340 × 1300 × 2300 mm
Weight≈ 2600 kg
Features
- Compact integrated design
- High energy density
- Space-efficient deployment
